Fusion XS Series 6.5" 200-Watt Classic Marine Speakers (Pair)

The Fusion XS Series 6.5" Classic marine speakers (pair) are a straightforward 200 W peak / 50 W RMS coaxial set for cockpits that need salt-friendly sound without RGB complexity. Classic grilles, 4 ohm nominal impedance, and an IP65 rating keep the install simple on bay boats and center consoles.

They pair cleanly with our MS-RA60 head unit, the RA60 speaker kit if you want a matched starter path, or a Fusion Apollo amp when you want more clean power. Recommended amp power for the 6.5" XS Classic is about 20 to 150 W RMS per channel.

Cutout is about 135 mm (5 5/16") with a minimum mounting depth around 67 mm (2 5/8"). Mount on a flat vertical surface and protect the rear of the speaker from spray.

See it in action

What you get

• Pair of Fusion XS Series 6.5" Classic marine speakers
• 200 W peak / 50 W RMS per speaker
• Frequency response about 80 Hz to 18 kHz
• 4 ohm nominal impedance
• IP65 water and dust rating
• Grilles and mounting hardware

Good to know

• Classic, not Sport LED: This SKU is the Classic pair (010-02196-00). No RGB lighting circuit to wire.
• RA60 friendly: Works with the MS-RA60 built-in amp for modest volume, or step up to an Apollo amp for more headroom.

Specs

• Size: 6.5"
• Efficiency: about 91 dB (1 W/1 m)
• Mounting diameter (clearance): 135 mm (5 5/16")
• Min. mounting depth: 67 mm (2 5/8")
• Fusion / Garmin part number: 010-02196-00
• UPC: 753759221409

In the box

• Two XS Series 6.5" Classic speakers
• Grilles
• Mounting screws and template
• Documentation
